- Optical System: Infinity optical system, f = 200mm, anti-mold.
- Viewing Head: Trinocular, Siedentopf type. Inclined 30°, rotatable 360°. Eyepoint height can be adjusted 180° to accommodate users of different builds. Interpupillary distance adjustment 50mm-75mm.
- Eyepieces: WF 10x/20mm focusing eyepieces. Eyepieces can be locked-in. Eyepiece accepts a 26.5mm reticle. Optional 12.5x, 15x and 20x eyepieces are also available.
- Nosepiece: Rear facing quintuple, ball bearing nosepiece with positive click stops to ensure parcentration. A quadruple nosepiece is also available.
- Objectives: Infinity Plan Achromat 4x, 10x, 40xR* and 100xR oil* (*spring-loaded).
- Stage: Rackless Mechanical Stage, size 150mm x 110mm with X-Y movement range of 76mm X 50mm.
- Condenser: Abbe condenser 0.9 dry/1.25 oil (with slots for sliders) on a rack and pinion with iris diaphragm.
- Stand: Cast alloy aluminum.
- Illumination: 3-watt LED with variable intensity control; LED bulb is rated for over 25,000 hours of continued use. Universal power supply 110v-240v.
- Focusing System: Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear.
- Accessories: Dust cover, immersion oil and instruction manual.
- Certification: ISO 9001: 2018 and ISO 14001: 2018; UL approved; CE anti-mold
- Warranty: 5-year limited warranty for parts, labor and electronic components; 1-year warranty on LED bulb
- Microscope Dimensions (LWH): 294mm x 199mm x 397mm
- Physical Weight: 24 lbs.
- Shipping size: 22x22x11 inches
- Shipping weight: 26 lbs.
